2.13" E-Ink Display with Touch & Front Light | GDEY0213B74-FT11

This e-paper（eInk / EPD） combines frontlight and touchscreen technology, preserving e-paper features like fast refresh and partial refresh, while offering touch operation in low-light conditions. Due to precise lamination requirements, the product is sold as a whole.
Number of views:
1000
Product serial number
65021300
Category
With Touch+Front-light
Quantity
-
+
Purchase Link Any request, please send us e-mail
1
OVERVIEW
SPECIFICATION
DOWNLOAD

GooDisplay Front-Lit Touch E-Ink Display

This highly integrated solution for the 2.13" E Ink display combines a capacitive touch layer with a uniform front light. It preserves ultra-low power consumption and a paper-like reading experience while providing smooth, responsive touch and soft, even illumination.





2.13" E Ink Display with Front Light & Touch

Based on the standard 2.13" GDEY0213B74model, it has been optimized for superior performance under various lighting conditions.

Display Size: 2.13 inches
Resolution: 250 × 122 pixels
Refresh Rate: Fast refresh: 1.5 s | Partial refresh: 0.3 s
Power Consumption: 9 mW (during refresh)
Features: Touchscreen, front light


Key Features

Ultra-Thin Design

Sleek, all-in-one form facto

Smart Power Management

Optimized touch and front-light efficiency.

Lossless Front Light

Paper-like clarity and transparency.

Adaptive Touch

Smooth and precise touch control.

Flexible Customization

Ideal for embedding and various applications.

Interaction & Display Balance

Fast refresh rates and smooth touch response.



Custom Front Light & Touch Module Solution

Engineered Cohesion

  • ✅ Fully compatible with any 2.13-inch E Ink display for seamless integration.
  • ✅ Dedicated QC team ensures the highest product standards for superior quality.
  • ✅ Comprehensive technical support from our expert team guarantees your success.

Multi-Mode Front Light Control

  • Selectable cold white or warm light modes.
  • Adjustable brightness by varying the number of LEDs.
  • Flexible circuit design supports series or parallel LED configuration.
  • Optional light guide plate (LGP) for uniform illumination.

Touch Technology Options

Choose the right technology for your application:

  • Customizable touch gestures for flexible, efficient refresh.
  • Customizable number of sensors and controller ICs.

Custom FPC & Interfaces

Tailored Flexible Printed Circuit (FPC) cables connect components (like EPDs) to meet your specific mechanical and electrical requirements. We design for optimal flexibility, routing, and connector types.

Mechanical Integration

Expert selection of OCA bonding and glass cover options (anti-glare, AF coating) ensures robust assembly, optical clarity, and a premium finish.



A typical custom Touch-Light module development takes 8–12 weeks, covering definition, design, validation, and initial production. Expedited timelines are available for urgent projects.

Demo: GooDisplay Front-Lit Touch E-Ink Display









Not Just Front Light & Touch


2.13 inch ePaper

2.13 inch ePaper with front light screen

2.13-inch ePaper with touch screen







E Ink Product Application



Transportation and Access Control   Industrial Control Terminals   Smart home application   Supermarket Smart tag








ESP32 Driver Solution



1) Optimal Matching Development Shield

GDEY0213B74-FT11

GDEY0213B74-FT11

+
ESP32-FT0213

ESP32-FT0213(Front-light & Touch Driver Board))

+
ESP32-L

ESP32 Main board

=
Composite Image

Composite Image



2) Matching Development Kit



GDEY0213B74-FT11

+

ESP32-FTS02

+
ESP32-L

ESP32 Main board

=

Complete Solution



How to Connect a 2.13" Frontlit Touch E-Paper Display to an ESP32

  •  DO NOT fold or pull the flex cable forcefully.
  •  Frontlight voltage must match specifications.
  •  If touch is unresponsive, check connection seating.
  •  Operate in dry conditions to avoid moisture damage.









STM32 Driver Solution

GDEY0213B74-FT11

GDEY0213B74-FT11

+
DESPI-F01

(Front-light Driver Board)

+
STM32-T01STM32-T01

(STM32 adapter Board)

+
STM32

STM32 Main board

=

Composite Image





Beyond the Product: Our Four Guarantees

Expert

Professional Technical Team

Experienced engineers provide full technical support, from solution design to application implementation.



7X24 RESPONSE

Quality

Quality Assurance

8-step quality control process with international certifications ensures 99.9% pass rate.



ISO9001 Certified

Experience

18 Years Experience

Serving tens of thousands of clients with proven industry expertise and problem-solving capabilities.

Knowledge Database
Capacity

Strong Stock Capacity

Ample stock of core products to ensure fast delivery and continuous production.

48-Hour Rapid Shipping
Keyword:
E-Ink Display Touch
Front-light e-paper display
2.13 inch E paper display
Supermarket price tag
E-paper
We could not find any corresponding parameters, please add them to the properties table

Note: This product requires high precision during bonding. For best results, we recommend purchasing the complete product. For detailed temperature specifications, please refer to the display's datasheet.

PARAMETERS

PART NUMBER

GDEY0213B74-FT11

TYPE

Dot Matrix

SIZE

2.13 inch

IC

SSD1680Z8

RESOLUTION

250x122

OUTLINE SIZE(mm)

59.2x29.2x2.15

ACTIVE SIZE(mm)

48.55x23.7

PIXEL PITCH(mm)

0.1942x0.1942

OPERATING TEMP

0℃~50℃

STORAGE TEMP

-25℃~70℃

CONNECTOR

24-pin FPC, pitch: 0.5 mm

MAX GRAYSCALE

4

COLOR

Black,White

INTERFACE

SPI

FULL REFRESH(s)

3

FAST REFRESH(s)

1.5

PARTIAL REFRESH TIME(s)

0.3

POWER CONSUMPTION OF THE REFRESH(mW)

9

STANDBY POWER CONSUMPTION (mW)

0.003


TOUCHSCREEN CONNECTOR

 6 Pin FPC
 TOUCHSCREEN IC TOUCH IC  FT6336U
TOUCHSCREEN VOLTAGE   2.8-3.6 V
TOUCHSCREEN OPERATING CURRENT 4.32mA
TOUCHSCREEN STANDBY CURRENT 55uA


FRONT-LIT CONNECTOR   6 pin FPC
FRONT-LIT NUMBER OF LED LIGHT   3
FRONT-LIT CIRCUIT MODE    Parallel
FRONT-LIT OPERATING VOLTAGE   2.8V-3.3V
FRONT-LIT OPERATING CURRENT  ≤45mA
